CS Unitec Portable Magnetic Drill with Swivel Base

Item No. SKU# MAB 485 SB
5 out of 5 Customer Rating
  • Available to Order
$1,91340
Out of Stock
+ $100 GIFT CARD w/ code at checkout
Delivery to -
43215
- Est. Arrival Thu Nov 14 - Thu Nov 21 Edit location
Pick Up at
Store Address -
Ready to pick up within 4 hours
Contact Store:
Made In USA
  Free Shipping (Ground shipping to lower 48)
Acme Tools Guarantee
CS Unitec Portable Magnetic Drill with Swivel Base
$1,91340
Out of Stock
+ $100 GIFT CARD w/ code at checkout
Qty
Secure Checkout
Affirm Pay as low as $93/mo with .
Product Details

CS Unitec Portable Magnetic Drill with Swivel Base

Description

CS Unitec Portable Magnetic Drill with Swivel Base

CS Unitec’s MAB 485 SB magnetic drill features a swivel base that provides 20˚ movement left and right and 5/8” forward and backward for drilling in hard-to-reach areas. The MAB 485 SB magnetic drill has a hole cutting capacity up to 2-1/16” dia. in structural steel and other metals. The 10.5 amp, double-insulated, reversible motor has a variable speed through a 2-gear oil bath gearbox (70-280 and 180-580 RPM) ideal for annular cutters and twist drills. Additional capabilities include twist drilling up to 7/8” dia., tapping up to 15/16” dia., reaming up to 7/8” dia. and countersinking up to 1-5/8”. This unit has a quick-change keyless cutter system for 3/4” Weldon Shanks, saving time and money. With a 3/4” drill chuck or MT2, the MAB 485 SB easily converts to a standard drill press. Integrated sensors in the MAB 485 SB include magnet overheating protection, visual magnet adhesion indication and an Electronic Safety Shutoff Sensor to automatically shut down the drill motor if the magnet loses contact with the material. An internal cable routing system helps protect the motor power cord from external damage. The magnet has a holding force of 8,000 lbs.

Features

Swivel base for easy, alignment without straining yourself. Magnetize and then adjust.
2-1/16" diameter hole cutting capacity
Professional-grade, variable speed, reversible through 2 gears amazing versatility
Excellent Power To Weight Ratio, Only 29 lbs
Integrated cable routing: No threading and getting caught, No tearing or snapping off
CoolMag™: reduces the power of the magnets when the drill motor is not active. Therefore, the mag drill won't build up heat.
SafeMag™: An LED indicator on the switch panel warns you of insufficient magnetic force (Red Light) or tells you if the correct force is present (Green Light).
Emergency-off function: electronic safety sensor shuts down drill motor if magnet loses contact with material to protect operator and equipment
Automatic internal lubrication
Morse Taper 3 to 3/4" Weldon Tool Holder

Specifications

Brand Name
CS Unitec
Amperage (A)
10.5
Assembled Weight (lbs)
27
California Proposition 65 Warning Required
Yes
Chuck Design
Keyless
Color
Blue
Country of Origin
Germany
Drill Press Type
Portable
Height (in)
11.61
Integrated Laser Guide
No
MFG Part # (OEM)
MAB 485 SB
Net Tool Weight (lbs)
29
Package Contents
(1) MAB 485 SB (1) Carrying Case (1) Safety Strap (1) Operating manual (1) Warranty Certificate (1) Coolant bottle (2) Pilot/Ejector Pin (2) Hex Keys (1) 3/4" Weldon Quick-Change Tool Holder w/ internal Lubrication, MT2 (1) 3/4" Standard Weldon Tool Holder w/ internal Lubrication, MT2 (1) 3/4" Geared Drill Chuck, MT2 (1) MT2 Drift Key (4) Tap Collet Adapters 1 each (1/4", 3/8", 1/2", 3/4")
Package Depth
23
Package Height
23
Package Weight
48
Package Weight (lbs)
32
Product Condition
New
Speeds
2
UL Listed
Yes
UPC
413000002125
Voltage
110 Volts
Warranty Type
1 Year Limited
