DK2 Elite Combat Winch 10000lb Steel Cable
VIEW IN AR
SCAN THE QR CODE TO VIEW THIS ITEM IN YOUR SPACE
INTERACT WITH 3D VIEW
Product Features
IP68 Rated Military Grade Winch & Control Box.
Hardened 3 stage planetary gears
Waterproof remote control with LED indicators.
Corrosion & Chemical Resistant Powder Coat
High Temperature Lithium Grease that won't solidify in extreme temperatures
Rated Line Pull 10000 lbs (4536 kgs)
Motor 12V :4.6kW / 6.2hp
24V : 6.5kW / 8.7hp
Gearing 228:1
Drum Size - Dia x L 63 x 217mm
(2.48 x 8.5 in)
Cable - Dia x L 9.1mm x 25m
(0.35 in x 82 ft)
Dimensions 574 x 16 x 259mm
(22.6 x 6.3 x 10.2 in)
Mounting Pattern 254 x 114.3mm
10 x 4.5 in
4-M10
Weight kg 37.5kg (82.7 lbs)
Layer of Rope/Cable Line Pull: lbs(kgs) Rope on drum ft(m)
1 10000 (4536) 16.1 (4.9)
2 7980 (3620) 36.4 (11.1)
3 6640 (3012) 61.0 (18.6)
4 5680 (2576) 82.0 (25.0
Line Pull
lbs (kgs) Line Speed 12v
ft/min (m/min) Line Speed 24v
ft/min (m/min) Amp Draw
12v Amp Draw
24v
0 32.2 (9.8) 34.4 (10.5) 65 45
3000 (1361) 14.8 (4.5) 16.4 (5.0) 140 85
6000 (2722) 10.5 (3.2) 12.5 (3.8) 260 140
8000 (3629) 7.5 (2.3) 9.8 (3.0) 320 175
10000 (4536) 5.2 (1.6) 7.5 (2.3) 380 210
-
In Stock (Ships in 3-5 business days)
$1,29999
Out of Stock
+
$100
GIFT CARD
w/ code at checkout
Delivery to -
43215
- Est. Arrival
Thu Nov 7 - Fri Nov 8
Edit location
Made In USA
Free Shipping (Ground shipping to lower 48)
DK2 Elite Combat Winch 10000lb Steel Cable
$1,29999
Out of Stock
+
$100
GIFT CARD
w/ code at checkout
Qty
(Max. order of 1,000)
Secure Checkout
Selected Store
Pay as low as
Product Details
DK2 Elite Combat Winch 10000lb Steel Cable
DK2
Description
DK2 Elite Combat Winch 10000lb Steel Cable
Built specifically for military use, able to withstand extreme climates & temps. Features include hardened 3 stage planetary gears for reliable and efficient use in the harshest environments. The waterproof remote control has thermometric LED indicators signals to monitor the temperature of the motor and high temp lithium grease is used which doesn’t solidify in extreme climates.
Features
IP68 Rated Military Grade Winch & Control Box.
Hardened 3 stage planetary gears
Waterproof remote control with LED indicators.
Corrosion & Chemical Resistant Powder Coat
High Temperature Lithium Grease that won't solidify in extreme temperatures
Rated Line Pull 10000 lbs (4536 kgs)
Motor 12V :4.6kW / 6.2hp
24V : 6.5kW / 8.7hp
Gearing 228:1
Drum Size - Dia x L 63 x 217mm
(2.48 x 8.5 in)
Cable - Dia x L 9.1mm x 25m
(0.35 in x 82 ft)
Dimensions 574 x 16 x 259mm
(22.6 x 6.3 x 10.2 in)
Mounting Pattern 254 x 114.3mm
10 x 4.5 in
4-M10
Weight kg 37.5kg (82.7 lbs)
Layer of Rope/Cable Line Pull: lbs(kgs) Rope on drum ft(m)
1 10000 (4536) 16.1 (4.9)
2 7980 (3620) 36.4 (11.1)
3 6640 (3012) 61.0 (18.6)
4 5680 (2576) 82.0 (25.0
Line Pull
lbs (kgs) Line Speed 12v
ft/min (m/min) Line Speed 24v
ft/min (m/min) Amp Draw
12v Amp Draw
24v
0 32.2 (9.8) 34.4 (10.5) 65 45
3000 (1361) 14.8 (4.5) 16.4 (5.0) 140 85
6000 (2722) 10.5 (3.2) 12.5 (3.8) 260 140
8000 (3629) 7.5 (2.3) 9.8 (3.0) 320 175
10000 (4536) 5.2 (1.6) 7.5 (2.3) 380 210
Specifications
Brand Name
DK2
Assembled Depth (in)
22.6
Assembled Weight (lbs)
82.7
Assembled Width (in)
6.3
Assembly Required
Yes
Color
Black
Country of Origin
China
Height (in)
10.2
MFG Part # (OEM)
T1000-100
Material
Steel
Package Contents
Elite Combat Winch 10000lb Steel Cable
Package Depth
13.18
Package Height
25
Package Weight
90.39
Product Condition
New
Sound Decibels (dB)
70 dBA
UPC
827518007167
Warranty Type
1 Year
