DK2 Ninja Winch Planetary Gear 3500lb with Synthetic Rope
VIEW IN AR
SCAN THE QR CODE TO VIEW THIS ITEM IN YOUR SPACE
INTERACT WITH 3D VIEW
Product Features
Sealed High Power Motor
Heavy Duty Watertight Contactors
Good for LARGE ATV's and small trailers, Suitable for synthetic rope
Full Steel planetary gearing strengthened steel drum, Watertight controller socket
Gloss chip resistant paint
Line Pull lbs Line Speed ft/min Flow L/min Pressure Mpa
0 10.5 45 25
1000 8.9 75 40
2000 7.5 130 75 3500 4.6 200 120
Layer of Wire Line Pull lbs
Rope ft
1 3500
2 2789
3 2319
4 1984 5 1733
Rated Line Pull 3500 lbs
Motor 12V: 1.95 HP Hydraulic Dis 3.38 oz/r
Gearing 170:1
Drum Size Dia x L 1.45 x 3.14 inch
Cable Dia x L 0.21 x 0.50 inch x 42 feet
Dimensions 13.62 x 4.45 x 4.64 inch
Weight 22.05 lbs
Mounting Pattern 5" x 3" inch
-
In Stock (Ships in 3-5 business days)
$29999
Out of Stock
+
$50
GIFT CARD
w/ code at checkout
Delivery to -
43215
- Est. Arrival
Thu Nov 7 - Fri Nov 8
Edit location
Made In USA
Free Shipping (Ground shipping to lower 48)
DK2 Ninja Winch Planetary Gear 3500lb with Synthetic Rope
$29999
Out of Stock
+
$50
GIFT CARD
w/ code at checkout
Qty
(Max. order of 1,000)
Secure Checkout
Selected Store
Pay as low as
Product Details
DK2 Ninja Winch Planetary Gear 3500lb with Synthetic Rope
DK2
Description
DK2 Ninja Winch Planetary Gear 3500lb with Synthetic Rope
DK2 Warrior Ninja 3500 Winch is Ideal for large ATV's and small trailers. A huge high power motor, heavy duty clutch, heavy duty steel gearing and heavy duty waterproof contactors ensure the ultimate in performance and reliability. Strengthened Steel drum makes it ideal to use with Synthetic Rope. Watertight 4 Pin connection allows the use of 'Plug and Play' Wireless. 1 Year Limited Warranty. Makes a great gift!
Features
Sealed High Power Motor
Heavy Duty Watertight Contactors
Good for LARGE ATV's and small trailers, Suitable for synthetic rope
Full Steel planetary gearing strengthened steel drum, Watertight controller socket
Gloss chip resistant paint
Line Pull lbs Line Speed ft/min Flow L/min Pressure Mpa
0 10.5 45 25
1000 8.9 75 40
2000 7.5 130 75 3500 4.6 200 120
Layer of Wire Line Pull lbs
Rope ft
1 3500
2 2789
3 2319
4 1984 5 1733
Rated Line Pull 3500 lbs
Motor 12V: 1.95 HP Hydraulic Dis 3.38 oz/r
Gearing 170:1
Drum Size Dia x L 1.45 x 3.14 inch
Cable Dia x L 0.21 x 0.50 inch x 42 feet
Dimensions 13.62 x 4.45 x 4.64 inch
Weight 22.05 lbs
Mounting Pattern 5" x 3" inch
Specifications
Brand Name
DK2
Assembled Depth (in)
13.62
Assembled Weight (lbs)
22
Assembled Width (in)
4.44
Assembly Required
Yes
Color
Black and Gray
Country of Origin
China
Height (in)
4.64
MFG Part # (OEM)
C3500N-SR
Material
Steel
Package Contents
Ninja Winch Planetary Gear 3500lb with Synthetic Rope
Package Depth
15.75
Package Height
8
Package Weight
24
Product Condition
New
Sound Decibels (dB)
70 dBA
UPC
826518005241
Warranty Type
1 Year
