DK2 Ninja Winch Planetary Gear 4500lb with Synthetic Rope
VIEW IN AR
SCAN THE QR CODE TO VIEW THIS ITEM IN YOUR SPACE
INTERACT WITH 3D VIEW
Product Features
Power in and Power out
High Torque 1.95hp Motor
HD Waterproof Contactors
Full Steel Planetary Gearing
Mount Plate as Standard
Full Load Holding Break
Rated Line Pull
4500 lbs (2041 kg)
Motor
12v : 1.95hp / 1.37kw
Gearing
172:1
Braking Action
Auto in the drum
Drum Size Dia x L
45 x 97mm
(1.77 x 3.82 in)
Cable/Rope Dia x L
6.4mm x 14.5m
(0.25 in x 48 ft)
Dimensions
360 x 126 x 165mm
(14.17 x 5 x 6.5 in)
Weight
13 kg (29 lbs)
Mounting Pattern
129 x 96 mm
(5.08 x 3.8 in)
Layer of Rope/Cable
Line Pull
lbs (kgs)
1
4500 (2041)
2
3642 (1652)
3
3060 (1388)
4
2638 (1196)
Line Pull lbs (kgs)
Line Speed
ft/min (m/min)
Amp Draw 12v
Amp Draw 24v
0
11.6 (3.6)
20
15
1500 (680)
9.2 (2.8)
70
40
2500 (1134)
7.8 (2.4)
100
65
3500 (1587)
6.6 (2.0)
140
80
4500 (2041)
4.9 (1.5)
200
129
-
In Stock
$37000
Out of Stock
+
$50
GIFT CARD
w/ code at checkout
Delivery to -
43215
- Get it as soon as Mon Nov 4th
Edit location
Made In USA
Free Shipping (Ground shipping to lower 48)
DK2 Ninja Winch Planetary Gear 4500lb with Synthetic Rope
$37000
Out of Stock
+
$50
GIFT CARD
w/ code at checkout
Qty
(Max. order of 1,000)
Secure Checkout
Selected Store
Pay as low as
Product Details
DK2 Ninja Winch Planetary Gear 4500lb with Synthetic Rope
DK2
Description
DK2 Ninja Winch Planetary Gear 4500lb with Synthetic Rope
High quality three stage planetary gearing ensure this is one of the quietest and smoothest winches on the market. The silky smooth performance and the full load holding brake make it the perfect solution for high spec applications.
Features
Power in and Power out
High Torque 1.95hp Motor
HD Waterproof Contactors
Full Steel Planetary Gearing
Mount Plate as Standard
Full Load Holding Break
Rated Line Pull
4500 lbs (2041 kg)
Motor
12v : 1.95hp / 1.37kw
Gearing
172:1
Braking Action
Auto in the drum
Drum Size Dia x L
45 x 97mm
(1.77 x 3.82 in)
Cable/Rope Dia x L
6.4mm x 14.5m
(0.25 in x 48 ft)
Dimensions
360 x 126 x 165mm
(14.17 x 5 x 6.5 in)
Weight
13 kg (29 lbs)
Mounting Pattern
129 x 96 mm
(5.08 x 3.8 in)
Layer of Rope/Cable
Line Pull
lbs (kgs)
1
4500 (2041)
2
3642 (1652)
3
3060 (1388)
4
2638 (1196)
Line Pull lbs (kgs)
Line Speed
ft/min (m/min)
Amp Draw 12v
Amp Draw 24v
0
11.6 (3.6)
20
15
1500 (680)
9.2 (2.8)
70
40
2500 (1134)
7.8 (2.4)
100
65
3500 (1587)
6.6 (2.0)
140
80
4500 (2041)
4.9 (1.5)
200
129
Specifications
Brand Name
DK2
Assembled Depth (in)
14.9
Assembled Weight (lbs)
34
Assembled Width (in)
7.9
Assembly Required
Yes
Color
Black and Gray
Country of Origin
China
Height (in)
5
MFG Part # (OEM)
C4500N-SR
Material
Steel
Package Contents
Ninja Winch Planetary Gear 4500lb with Synthetic Rope
Package Depth
15.75
Package Height
8
Package Weight
36
Product Condition
New
Sound Decibels (dB)
70 dBA
UPC
826518005265
Warranty Type
1 Year
