JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer

Item No. SKU# 311446J
5 out of 5 Customer Rating
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, large image number 0
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, large image number 1
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, large image number 2
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, large image number 3
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, large image number 4
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, large image number 5
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, large image number 6
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, large image number 7
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, large image number 8
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, small
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, small
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, small
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, small
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer, small
+ 4 more
  • Available to Order
$20,79900
Out of Stock
+ $100 GIFT CARD w/ code at checkout
Delivery to -
43215
- Est. Arrival Thu Nov 14 - Thu Nov 21 Edit location
Pick Up at
Store Address -
Ready to pick up within 4 hours
Contact Store:
Made In USA
  No Air Shipments
  Free Freight  Shipping  (Truck freight shipping to lower 48)
Acme Tools Guarantee

Lift Gate Service (freight lowered to ground)
JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer
$20,79900
Out of Stock
+ $100 GIFT CARD w/ code at checkout
Qty
Secure Checkout
Affirm Pay over time with Affirm on orders below $17,500
Product Details

JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer

JET JET

Description

JET 14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer

The EVS-1440B is engineered to maximize your shop’s output. The D1 4 spindle is precision ground for accuracy and supported by class 7 tapered roller bearings capable of a run out maximum of .0004 In.. the 2 speed gearbox allows operators to easily work at low speeds from 40 to 365 RPM and at high speeds from 220 to 2,000 RPM's.

California Proposition 65 Warning.
View Warning Label

Features

V-way bed design is induction hardened and ground
Splined, not keyed, shafts are utilized
D1-4 spindle is precision ground for accuracy and supported by high quality tapered roller bearings
Independent lead screw and feed rod
Adjustable gibs are incorporated in the carriage and slide ways
Class 7 precision taper roller bearings keep spindle run out to a maximum of 0.0004"
Meehanite castings retain their tolerance and remain rigid through many years of machining
14 x 40 Electronic Variable Speed Lathe with ACU-RITE 203 DRO and Collet Closer, 3 HP, 230/460 V, 3Ph
Emergency stop within easy reach of the operator
Electronic chuck key docking station

Specifications

Brand Name
JET
Assembled Weight (lbs)
1320
California Proposition 65 Warning Required
Yes
Center To Center (in)
40
Color
Gray
Country of Origin
Taiwan
ETL Listed
No
Height (in)
50
Horsepower (hp)
3
MFG Part # (OEM)
311446J
Maximum Speed (rpm)
1800
Net Tool Weight (lbs)
1320
Package Contents
14 x 40 Lathe with ACU-RITE 203 DRO & Collet Closer
Package Depth
68.5
Package Height
50
Package Weight
1584
Package Weight (lbs)
1584
Product Condition
New
UL Listed
No
UPC
731325791990
Variable Speed
Yes
Voltage
230/460 Volts
Warranty Type
2 Years Limited
