JET 14 x 40 Single Phase Gear Head Lathe with Collet Closer
VIEW IN AR
SCAN THE QR CODE TO VIEW THIS ITEM IN YOUR SPACE
INTERACT WITH 3D VIEW
Product Features
V-way bed design is induction hardened and ground
Splined, not keyed, shafts are utilized
D1-4 spindle is precision ground for accuracy and supported by high quality tapered roller bearings
Independent lead screw and feed rod
Adjustable gibs are incorporated in the carriage and slide ways
Safety on/off switch
Emergency stop within easy reach of the operator
Electronic chuck key docking station
Chuck guard
Foot brake
-
In Stock (Ships in 3-5 business days)
$18,79900
Out of Stock
+
$100
GIFT CARD
w/ code at checkout
Delivery to -
43215
- Est. Arrival
Thu Nov 7 - Fri Nov 8
Edit location
Made In USA
Free Freight
(Truck freight shipping to lower 48)
Lift Gate Service
(freight lowered to ground)
JET 14 x 40 Single Phase Gear Head Lathe with Collet Closer
$18,79900
Out of Stock
+
$100
GIFT CARD
w/ code at checkout
Qty
(Max. order of 1,000)
Secure Checkout
Selected Store
Pay over time with Affirm on orders below $17,500
Product Details
JET 14 x 40 Single Phase Gear Head Lathe with Collet Closer
JET
Description
JET 14 x 40 Single Phase Gear Head Lathe with Collet Closer
The new Jet GH-1440-1 and GH-1440-3 geared head engine lathes weigh over one ton and come equipped with precision induction hardened ground bed-ways, spindle roller bearings, and high-quality steel hardened gears in the headstock for the ultimate working durability. The enclosed gearbox design, standard coolant system, and lead screw cover provide a smooth and quiet operation while maintaining peak performance. The GH-1440-1 and GH-1440-3 also includes a patented electronic chuck key docking station that prevents startup without the chuck key when safely docked.
View Warning LabelFeatures
V-way bed design is induction hardened and ground
Splined, not keyed, shafts are utilized
D1-4 spindle is precision ground for accuracy and supported by high quality tapered roller bearings
Independent lead screw and feed rod
Adjustable gibs are incorporated in the carriage and slide ways
Safety on/off switch
Emergency stop within easy reach of the operator
Electronic chuck key docking station
Chuck guard
Foot brake
Specifications
Brand Name
JET
Assembled Weight (lbs)
2336.0
California Proposition 65 Warning Required
Yes
Center To Center (in)
40.0
Color
Gray
Country of Origin
China
ETL Listed
No
Height (in)
46.0
Horsepower (hp)
3.0
MFG Part # (OEM)
323372
Maximum Speed (rpm)
1720.0
Net Tool Weight (lbs)
2336.0
Package Contents
14 x 40 Single Phase Gear Head Lathe with Collet Closer
Package Depth
0
Package Height
0
Package Weight
2336.0
Package Weight (lbs)
2336
Product Condition
New
Swing Over Bed
14.0
UL Listed
Yes
UPC
731325733556
Variable Speed
No
Voltage
230 Volts
Warranty Type
2 Years Limited
