JET GH-2280ZX with ACU-RITE 303 DRO Metalworking Lathe
VIEW IN AR
SCAN THE QR CODE TO VIEW THIS ITEM IN YOUR SPACE
INTERACT WITH 3D VIEW
Product Features
3-1/8” bore spindle is supported by two tapered and one ball bearings
Universal gearbox allows inch, metric, diametrical and module pitch threads, no change gears required
One piece cast iron base absorbs vibration allowing heavier cuts
High quality ANSI class 50 wear resistant cast iron bed ways are hardened and ground
Siemens Electrics
Front Removable Chip Tray
Safety Holder for Chuck Key. Chuck Key must be in Holder for lathe to operate
Large easy to use foot brake
Chrome molybdenum headstock gears are hardened, ground and shaved
Carriage features one-shot lubrication and Turcite-B on bed sliding surfaces
-
Available to Order ✖This is an estimate only.
You will receive an email notifying you if this shipping date changes.
$39,89900
Out of Stock
+
$100
GIFT CARD
w/ code at checkout
Delivery to -
43215
- Est. Arrival
Fri Nov 15 - Fri Nov 22
Edit location
Made In USA
Free Freight
(Truck freight shipping to lower 48)
Lift Gate Service
(freight lowered to ground)
JET GH-2280ZX with ACU-RITE 303 DRO Metalworking Lathe
$39,89900
Out of Stock
+
$100
GIFT CARD
w/ code at checkout
Qty
(Max. order of 1,000)
Secure Checkout
Selected Store
Pay over time with Affirm on orders below $17,500
Product Details
JET GH-2280ZX with ACU-RITE 303 DRO Metalworking Lathe
JET
Description
JET GH-2280ZX with ACU-RITE 303 DRO Metalworking Lathe
The ZX-Series Large Spindle Bore Lathe provides power, precision, efficiency and reliability to your metal shop. A one piece cast iron base absorbs vibrations during operation to allow heavier cuts and ensure accuracy, while the Universal Gearbox eliminates the need to change gears. Features you've come to expect in a JET Lathe that is backed by the industry-leading JET Two Year Warranty.
View Warning LabelFeatures
3-1/8” bore spindle is supported by two tapered and one ball bearings
Universal gearbox allows inch, metric, diametrical and module pitch threads, no change gears required
One piece cast iron base absorbs vibration allowing heavier cuts
High quality ANSI class 50 wear resistant cast iron bed ways are hardened and ground
Siemens Electrics
Front Removable Chip Tray
Safety Holder for Chuck Key. Chuck Key must be in Holder for lathe to operate
Large easy to use foot brake
Chrome molybdenum headstock gears are hardened, ground and shaved
Carriage features one-shot lubrication and Turcite-B on bed sliding surfaces
Specifications
Brand Name
JET
Assembled Weight (lbs)
7450.0
California Proposition 65 Warning Required
Yes
Center To Center (in)
80.0
Color
White
Country of Origin
China
CSA Certified
No
ETL Listed
No
Height (in)
49.0
Horsepower (hp)
10.0
MFG Part # (OEM)
321610
Maximum Speed (rpm)
1800.0
Net Tool Weight (lbs)
7450.0
Package Contents
GH-2280ZX with ACU-RITE 303 DRO Metalworking Lathe
Package Depth
0
Package Height
0
Package Weight
7650.0
Package Weight (lbs)
7650
Product Condition
New
Spindle Bore Diameter
0.0
UL Listed
No
UPC
731325173338
Variable Speed
Yes
Voltage
230/460 Volts
Warranty Type
2 Years Limited
